SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Sine-wave filters
4/98
Siemens D 11.1 · 2009
4
■
Technical specifications
Line supply voltage
380...480V3AC
Sine-wave filter (for pulse frequencies 4 kHz ... 8 kHz)
6SL3202-0AE21-1SA0 6SL3202-
0AE21-4SA0
6SL3202-
0AE22-0SA0
6SL3202-0AE23-3SA0
Rated current A 9.0 9.0 14.0 20.0 33.0 33.0
Power loss kW 0.02 0.02 0.02 0.06 0.06 0.06
Connection to the
Power Module
Cable Cable Cable Cable Cable Cable
• Conductor cross-section mm
2
6 6 6 10 10 10
• Length, approx. m 0.5 0.5 0.5 0.5 0.5 0.5
Motor connection Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
6 6 6 10 10 10
PE connection M5 screw studs M5 screw studs M5 screw studs M5 screw studs M5 screw studs M5 screw studs
Cable length, max.
between sine-wave filter and
motor
•380...480V3AC±10 %
- Shielded m 200 200 200 200 200 200
- Unshielded m 300 300 300 300 300 300
Dimensions
• Width mm 153 153 153 189 189 189
•Height mm 270 270 270 336 336 336
•Depth mm 100 100 100 140 140 140
Possible as base
component
yes yes yes yes yes yes
Degree of protection IP20 IP20 IP20 IP20 IP20 IP20
Weight, approx. kg 6 6 10 12 23 23
Suitable for
PM240 Power Module
Type 6SL3224-
0BE22-2UA0
6SL3224-
0BE22-2AA0
6SL3224-
0BE23-0UA0
6SL3224-
0BE23-0AA0
6SL3224-
0BE24-0UA0
6SL3224-
0BE24-0AA0
6SL3224-
0BE25-5UA0
6SL3224-
0BE25-5AA0
6SL3224-
0BE27-5UA0
6SL3224-
0BE27-5AA0
6SL3224-
0BE31-1UA0
6SL3224-
0BE31-1AA0
Suitable for
PM250 Power Module
Type – – – 6SL3225-
0BE25-5AA0
6SL3225-
0BE27-5AA0
6SL3225-
0BE31-1AA0
Rated power of the
Power Module
kW (hp) 2.2 (3) 3 (4) 4 (5) 7.5 (10) 11 (15) 15 (20)
Rated current I
rated
of the
Power Module
A 5.9 7.7 10.2 18 25 32
Frame size
FSB FSB FSB FSC FSC FSC
