SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Sine-wave filters
4/99
Siemens D 11.1 · 2009
4
■
Technical specifications
Line supply voltage
380...480V3AC
Sine-wave filter (for pulse frequencies 4 kHz ... 8 kHz)
6SL3202-0AE24-6SA0 6SL3202-
0AE26-2SA0
6SL3202-0AE28-8SA0
Rated current A 47 47 61.8 92 92
Power loss kW 0.2 0.2 0.2 0.17 0.27
Connection to the
Power Module
Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
50 50 50 95 95
Motor connection Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
50 50 50 95 95
PE connection M6 screw M6 screw M6 screw M8 screw M8 screw
Cable length, max.
between sine-wave filter and
motor
•380...480V3AC±10 %
- Shielded m 200 200 200 200 200
- Unshielded m 300 300 300 300 300
Dimensions
• Width mm 250 250 250 275 275
•Height mm 315 315 305 368 368
•Depth mm 262 262 262 275 275
Possible as base
component
no no no no no
Degree of protection IP00 IP00 IP00 IP00 IP00
Weight, approx. kg 24.0 24.0 34.0 45.0 45.0
Suitable for
PM240 Power Module
Type 6SL3224-
0BE31-5UA0
6SL3224-
0BE31-5AA0
6SL3224-
0BE31-8UA0
6SL3224-
0BE31-8AA0
6SL3224-
0BE32-2UA0
6SL3224-
0BE32-2AA0
6SL3224-
0BE33-0UA0
6SL3224-
0BE33-0AA0
6SL3224-
0BE33-7UA0
6SL3224-
0BE33-7AA0
Suitable for
PM250 Power Module
Type 6SL3225-
0BE31-5 . A0
6SL3225-
0BE31-8 . A0
6SL3225-
0BE32-2 . A0
6SL3225-
0BE33-0 . A0
6SL3225-
0BE33-7 . A0
Rated power of the
Power Module
kW (hp) 18.5 (25) 22 (30) 30 (40) 37 (50) 45 (60)
Rated current I
rated
of the
Power Module
A 38 45 60 75 90
Frame size FSD FSD FSD FSE FSE
