Sinclair ASGE-18AI User Manual

Continued: 1
Indoor unit ASF-24AI ASF-36AI
Models
Outdoor unit ASGE-24AI ASGEASGE-36AI
kW 7.0 10.0
Cooling
Btu/h 24000 34100
kW 8.0 12.0
Nominal
Capacity
Heating
Btu/h 27300 40900
Cooling kW 2.43 3.35 Power
Input
Heating kW 2.2 3.95
EER/COP W/W 2.88/3.64 2.98/3.04
Indoor Unit
Power Supply

220-240V~/1 Ph/50HZ
Heat Exchange

Cross Fin Coil
Type

Centrifugal fan
Drive

Direct Driver
Motor Output kW 0.1 0.085
Fan
Air Flow m
3
/h
117
0 1800
Sound Pressure Level(H/M/L) dB(A) 50/48/46 54/51/48
Air Filter

Standard washable synthetic
Drain Piping mm φ28×1.5 φ28×1.5
Dimensions (H×W×D)
(Outline/Package)
mm
1300×188×600
/1414×248×724
1590×238×695/
1714×330×830
Weight(Net/Gross) kg 33/40 48/58
Outdoor Unit
Power Supply

220-240V~/1 Ph/50HZ
Heat Exchange

Cross Fin Coil
Type ― Axial fan
Motor Output kW 0.068 0.092×2
Fan
Fan Motor Speed (H/M/L) rpm 840/620/400 940/-/700
Type

ROTARY SCROLL
Compressor
Power Input W 1630 3240
Type

R410A
Control

Electronic expansion valve
Refrigerant
Charge kg 1.8
4.0
Dimensions (W×H×D)
(Outline/Package)
mm
913×680×378
/994×750×428
1032×1250×412
/1110×1385×450
Weight(Net/Gross) kg 51/55 128/139
Liquid mm 9.52 12.7
Gas mm 15.8 19.05
Max. Length m 30 50
Piping
Connections
Max. Height Difference m 15 30
ASF-24AI
ASF-36AI
ASGE-24AI
ASGE-36AI
