Connect to
WZ863
PCB CN1
Power N
Power L Connect to
WZ863 PCB
CN15
Silkscreen Interface
X1 Live Wire
X2 Neutral Wire
CN8 To 14-cord Wire
Z814B
CN3
To 3-cord Wire
Fig8 ZB Z814B Interface Diagram
Power Out N L3 L2 L1
Power IN N L3 L2 L1
GND
