Indoor unit ASF-24AI ASF-36AI S
Models
Outdoor unit ASGE-24AI S ASGE-36AI S
kW 7.0 10.0
Cooling
Btu/h 24000 34100
kW 8.0 10.8
Nominal
Capacity
Heating
Btu/h 27300 36800
Cooling kW 2.43 3.4 Power
Input
Heating kW
2.20 2.90
EER/COP W/W 2.88/3.64 2.94/3.72
Indoor Unit
Power Supply

220~240V-50Hz-1Ph
Heat Exchange

Cross Fin Coil
Type

Centrifugal fan
Drive

direct
Motor Output kW 0.05×1 0.085×1
Fan
Air Flow m
3
/h 1170 1800
Sound Pressure Level(H/M/L) dB(A) 50/48/46 54/51/48
Air Filter

Standard washable synthetic
Drain Piping mm
17×2.5
Dimensions (H×W×D)
(Outline/Package)
mm
1300×188×600/14
14×248×724
1590×238×695/
1 714×330×830
Weight(Net/Gross) kg
33/40
48/58
Outdoor Unit
Power Supply

220~240V-50Hz-1Ph
Heat Exchange

Cross Fin Coil
Type ― Axial fan
Motor Output kW 0.068×1 0.093×1
Fan
Fan Motor Speed (H/M/L) rpm 840/620/400 780/-/500
Type

ROTARY
Compressor
Power Input W 1630 3010±7.5%
Type

R410A
Control

Electronic expansion valve
Refrigerant
Charge kg 1.8 2.6
Dimensions (W×H×D)
(Outline/Package)
mm
913×680×378/
994×750×428
980×790×427/
1080×840×485
Weight(Net/Gross) kg 51/55 70/78
Liquid mm
9.52
9.52
Gas mm 15.88 15.88
Max. Length m 30
Piping
Connections
Max. Height Difference m 15
ASF-24AI
ASGE-24AI S
ASF-36AI S
ASGE-36AI S
