4.1.3 Cassette Type
Indoor unit ASC-18AI ASC-24AI ASC-36AI
Models
Outdoor unit ASGE-18AI ASGE-36AI
kW 5.0 7.0 10.0
Cooling
Btu/h 17000 24000 341
kW 5.8 8.0 12.0
Nominal
Capacity
Heating
Btu/h 19800 27300 40900
Cooling kW 1.71 2.49 3.4
Power
Input
Heating kW 1.93 2.11 4.0
EER/COP W/W 2.92/3.00 2.81/3.79 2.98/3.00
Indoor Unit
Power Supply  220-240V~/1 Ph/50HZ
Heat Exchange  Cross Fin Coil
Type  Centrifugal fan
Drive  Direct Driver
Motor Output kW 0.011 0.035 0.06
Fan
Air Flow m
3
/h 680 1180 1660
Sound Pressure Level(H/M/L) dB(A) 47/45/42 47/45/42 53/51/48
Air Filter  Standard washable synthetic
Drain Piping mm φ31×3 φ32×3 φ32×3
Indoor Unit Dimensions
(Outline/Package) (W×H×D)
mm
600×230×600
/848×310×678
840×240×840
/960×310×960
840×320×840
/960×394×960
Weight(Net/Gross) kg 20/27 30/38 32/43
Panel Dimensions
(Outline/Package) (W×H×D)
mm
650×50×650
/670×102×730
950×60×950
/1025×115×1040
950×60×950
/1025×115×1040
Panel Weight(Net/Gross) kg 2.5/3.5 6.5/10 6.5/10
Outdoor Unit
Power Supply  220-240V~/1 Ph/50HZ
Heat Exchange  Cross Fin Coil
Type ― Axial fan
Motor Output kW 0.03 0.068 0.093×2
Fan
Fan Motor Speed (H/M/L) rpm 850 840/620/400 940/-/700
Type  ROTARY SCROLL
Compressor
Power Input W
1630 3240
Type  R410A
Control  Electronic Expansion Valve
Refrigerant
Charge kg 1.5 1.8 4.0
Dimensions (W×H×D)
(Outline/Package)
mm
820×540×320/
878×590×360
913×680×378
994×750×428
1032×1250×412/
1110×1385×450
Weight(Net/Gross) kg 36/40 51/55 128/139
Liquid mm 6.35 9.52 12.7
Gas mm 12.7 15.8 19.05
Max. Length m 20 30 50
Piping
Connections
Max. Height Difference m 15 15 30
ASC-18AI
ASGE-18AI
ASC-24AI
ASGE-24AI
ASC-36AI
ASGE-36AI
ASGE-24AI
