Sinclair ASGE-18AI User Manual

Continued: 4
Indoor unit
ASC-36AI S ASC-42AI S
Models
Outdoor unit ASGE-42AI-3 S
kW 10.0 11.9
Cooling
Btu/h 34100 40600
kW 10.8 13.0
Nominal
Capacity
Heating
Btu/h 36800 44300
Cooling kW 3.60 4.22
Power
Input
Heating kW 3.0 4.0
EER/COP W/W 2.78/3.6 2.82/3.25
Indoor Unit
Power Supply － 220~240V-50Hz-1Ph
Heat Exchange － Cross Fin Coil
Type － centrifugal fan
Drive － Direct Driver
Motor Output kW 0.06×1 0.06×1
Fan
Air Flow m
3
/h 1800 1660
Sound Pressure Level(H/M/L) dB(A) 54/51/48 53/51/48
Air Filter － Standard washable synthetic
Drain Piping mm φ32×3 φ32×3
Indoor Unit Dimensions
(Outline/Package) (W×H×D)
mm
840×320×840/
960×394×960
840×320×840/
960×394×960
Weight(Net/Gross) 32/43 32/43
Panel Dimensions
(Outline/Package) (W×H×D)
mm
950×60×950
/1025×115×1040
950×60×950
/1040×115×1025
Panel Weight(Net/Gross) kg 6.5/10 6.5/10
Outdoor Unit
Power Supply － 380~415V-50Hz-3Ph 220~240V-50Hz-1Ph
Heat Exchange －
Cross Fin Coil
Type ― Axial fan
Motor Output kW 0.093×1
Fan
Fan Motor Speed (H/M/L) rpm 780/-/500 820±20
Type － ROTARY
Compressor
Power Input W
3010±7.5%
Type － R410A
Control － Electronic expansion valve
Refrigerant
Charge kg 2.6 3.5
Dimensions (W×H×D)
(Outline/Package)
mm
980×790×427
/1080×840×485
1107×1100×440
/1155×1220×490
Weight(Net/Gross) kg 70/78
88/98
Liquid mm 9.52
Gas mm 15.88
Max. Length m 30 50
Piping
Connections
Max. Height Difference m 15 30
ASC-36AI S
ASGE-36AI-3 S
ASGE-36AI-3 S
ASC-42AI S
ASGE-42AI-3 S
