1 Left Decoration Plate 26112417 1 AE
2 Shaft of Louver 10512025 2 AB
3 Swing Louver Fixer 01332410 1 AG
4 Louver Support 24212020 3 AC
5 Louver Fixer 24222016 2 AC
6 Guide Louver 10512404 1 AH
7 Shaft of Louver 10512026 2 AB
8 Right Decoration Plate 26112421 1 AE
9 Motor Left Clamp 26152007 1 AD
10 Front Panel Sub-Assy 01532414 1 AU
11 Display Box 20102138 1 AD
12 Display Board 30545654 1 AW
13 Buttons Panel 20162004 1 AE
14
Motor Right Clamp (Right
Swing Motor Fixer) 26152008 1 AD
15 Stepping Motor 15212402 2 AF
16 Motor Clamp 26112026 4 AC
17 Water Tray 01272411 1 AZ
18 Auxiliary Water Tray 01272413 1 AN
19 Tube Clip 70812001 1 AB
20 Drain Pipe Sub-Assy 05235433 1 AE
21 Handle 26232001 4 AD
22 Right Side Foam 12312408 1 AD
23 Mounting Plate 01332404 1 AH
24 Support Of Motor Bearing 01792408 2 AC
25 Fixer of Motor Support 01792409 1 AF
26 Right Decoration Panel 26112033 1 AL
27 Pipe Clamp 01072424 1 AC
28 Electric Box Sub-Assy 01402407 1 AG
29 Wire Base 24253001 1 AC
30 Wire Clamp 24253002 1 AC
31 Terminal Board 42011159 1 AD
32 Fuse 5A/250V 46010013 1 AA
33 Main PCB Z7A251B 30227021 1 BA
34 O-Gasket of Bearing 76512404 2 AC
35 Fan Bearing 76512210 2 AC
Part no. 1
The data are subject to change without notice.
Price
rank
ASF-24AI, ASF-24AI S Indoor unit
Parts List for ASF-24AI Indoor unit
No. Description Parts No. Qty
To Next Page
