8.0 Spare Parts Duro Stripper
Schematic # Pieces Description Part #
1 1 Striker Foot Casting D015221
3 1 Blade holder D015223
4 1 Bearing plate D015224
5 1 Drive shaft D015228
6 1 Grip frame D015227
7 1 Hand grip D014916
8 1 Locking flange / Bearing Plate D015233
9 1 Counter Balance Weight D015225
10 1 Crown wheel / Ring Gear D015234
11 4 Rubber bearings D014931
12 1 Fitting spring, 5x 6,5 / Woodruff Key D014905
13 1 Sealing ring / O-Ring D015218
14 1 Distance ring D015217
15 1 Locking clip I 52 / Snap Ring D014857
16 1 Ball bearings 6304 2RS C3 D014711
17 8 Cyl. screw, M6x20 D014752
18 4 Washer, M6 D014859
19 4 Nylock Nut, M6 D014815
20 4 Cyl screw, M5x25 micro T014721
21 4 Safety washer, M5 T014858
22 1 Ball bearing 3304 2RS C3 D014674
23 1 Washer, M12 D014830
24 1 Countersink Screw M8x20 T014760
26 1 Shaft Seal for Gear Head D014847
27 8 Nylock Nut M6x1.0 D014815
28 4 Cyl. screw, M6x14 D014751
29 4 Safety washer, M6 D014858
30 4 Cap Screw, M6x22 D00912415B
31 2 Hexagon screw, M14x35 D009167000N
32 2 Hexagon screw, M8x20 D014775
33 2 Safety washer, M14 D014863
34 1 Rubber sleeves D014932
35 1 Foot switch D015023
36 2 Counter sunk screw M5x70 (Spax) D014797
37 2 Safety washer, M8 D014860
39 1 Baffle D015433
40 1 Gear block housing D015189
41 1 Needle bearing HK 1512 D015190
42 4 Cyl. screw, M5x45 D015191
43 1 Hexagon nut, M10 D015192
44 1 Pinion D015193
45 1 Sealing bushing D015194
46 1 Ball bearing D014709
47 1 Sealing ring D015195
48 1 Cover D015196
49 1 Counter sink screw, M5x16 D015197
51 1 Ball bearing 6001/2RS D014701
52 1 Bearing ring D015199
