Sinclair KEYON Series - Outdoor Unit Installation; Outdoor Unit Installation Notice

19
Parts name
Outdoor Unit
NOTE
●
Actual product may be different from above graphics, please refer to actual product.
air inlet
air outlet
Installation notice
Drainage pipe
Space to the obstruction
At least 50cm
Space to the obstruction
At least 30cm
Space to the obstruction
At least 50cm
Space to the obstruction
At least 200cm
At least 30cm
Space to the wall
Please contac
t
the local agent for installation.
Don’t use unqualified power cold.
NOTICE
●
●
