Singer Valve 106-PG - Page 8

For Anti-Cavitation (-AC) trim equipped valves please see PG-AC spec sheet January 2006
12850-87
th
Avenue
Surrey, BC. Canada. V3W 3H9
Ph: 604-594-5404
Fx: 604-594-8845
www.singervalve.com
Material Specifications & Dimensions
10” to 16” (250mm to 400mm) S106-PG & SA106-PG
12” to 24” (300mm to 600mm) S206-PG
For Drawing A0867C
Item
Part Name Material Item Part Name Material
1. Body Ductile Iron
2. Bonnet Ductile Iron
3. Spring Casing Ductile Iron
6. Bottom Guide Ductile Iron & Stainless Steel
7. Seat Ring Stainless Steel
8. Seat Ring Washers Stainless Steel
9. Stem Stainless Steel
10. Disc Retainer Ductile Iron
11.** Resilient Disc EPDM or Buna-N
12. Inner Valve Ductile Iron
13. Piston Ductile Iron
14. Clamp Plate Ductile Iron
15.** Diaphragm EPDM or Buna-N
16. Stem Nut Stainless Steel
17. Spring Stainless Steel
18. Bonnet Locating Pins Steel
19. Bleed Valve Stainless Steel
20.** Seat Ring Seal Buna-N
21.** Spring Casing Seal Buna-N
22.** Stem Seals Buna-N
23. Bonnet Bolts Stainless Steel
24. Bonnet Washers Stainless Steel
25. Spring Casing Locating Pins Steel
26. Spring Casing Screw Stainless Steel
27. Spring Casing Washers Stainless Steel
28. Seat Ring Screw Stainless Steel
29. Eye Bolt Steel
31. Clamp Plate Screw Stainless Steel
32. Inner Valve Screw Stainless Steel
** Recommended spare parts (included in the Rebuild Kit)
Globe Globe & Ang Angle
S106-PG & SA106-PG
A D E C B E F
10”
250mm
150F / PN10, PN16
29.75”
756mm
8.56”
217mm
23.31”
592mm
22.13”
562mm
11.50”
292mm
20”
508mm
12.50”
318mm
300F / PN25, PN40
31.12”
790mm
9.56”
243mm
23.31”
592mm
22.13”
562mm
12.19”
310mm
20”
508mm
13.19”
335mm
12”
300mm
150F / PN10, PN16
34”
864mm
9.50”
241mm
26.75”
679mm
26”
660mm
13.75”
349mm
23.75”
603mm
12.50”
318mm
300F / PN25, PN40
35.50”
902mm
10.25”
260mm
26.75”
679mm
26”
660mm
14.50”
368mm
23.75”
603mm
13.25”
337mm
14”
350mm
150F / PN10, PN16
31”
787mm
10.50”
267mm
26.80”
681mm
26”
660mm
- - -
300F / PN25, PN40
32.50”
826mm
11.50”
292mm
26.80”
681mm
26”
660mm
- - -
16”
400mm
150F / PN10, PN16
41.38”
1051mm
11.75”
298mm
31.40”
798mm
32”
813mm
18”
457mm
28.50”
724mm
15.69”
399mm
300F / PN25, PN40
43.50”
1105mm
12.75”
324mm
31.40”
798mm
32”
813mm
18.81”
478mm
28.50”
724mm
16.50”
419mm
Globe Globe & Ang Angle
S206-PG
A D E C B E F
12”
300mm
150F / PN10, PN16
27.50”
699mm
9.50”
241mm
23.35”
593mm
22.12”
562mm
- - -
300F / PN25, PN40
29”
737mm
10.50”
267mm
23.35”
593mm
22.12”
562mm
- - -
16”
400mm
150F / PN10, PN16
36”
914mm
11.75”
298mm
26.75”
679mm
26”
660mm
- - -
300F / PN25, PN40
37.63”
956mm
12.75”
324mm
26.75”
679mm
26”
660mm
- - -
18”
450mm
150F / PN10, PN16
42”
1067mm
12.50”
318mm
31.38”
797mm
30.31”
770mm
- - -
300F / PN25, PN40
43.63”
1108mm
14”
356mm
31.38”
797mm
30.31”
770mm
- - -
20”
500mm
150F / PN10, PN16
45”
1143mm
13.75”
349mm
31.38”
797mm
30.50”
775mm
- - -
300F / PN25, PN40
46.38”
1178mm
15.25”
387mm
31.38”
797mm
30.50”
775mm
- - -
24”
600mm
150F / PN10, PN16
50.50”
1283mm
16”
406mm
31.38”
797mm
36”
914mm
- - -
300F / PN25, PN40
52.25”
1327mm
18”
457mm
31.38”
797mm
36”
914mm
- - -
