(4) Threading the Right Needle (Green)
* Thread the right needle as indicated © ~
(D .
'Tsmi—D
* Pass thread from back to the front through the
thread guide 0.
* Insert thread down through the right hole.
* Bring thread up and insert through top of left hole
* Hold the thread above tension disc to stabilize it
(D-A.
* Pass the thread between the tension discs (3)-B.
* Pull thread up and over the top of the metal finger
@>-C.
* Pull thread down to make certain it is properly
threaded between the tension discs.
16
