Singer One Plus - Motor Belt Tension

Page 29/41
Original issue
Oct.2012
Service Manual
One Plus
Model
15. Motor belt tension
Adjustment:
1. Remove the front cover.
2. Loosen two nuts (A) and adjust belt tension so that belt may be bent about 5 mm when it is
pushed by pressure of 100g between upper shaft and motor.
3. Tighten the two nuts after checking the belt tension.
A
