Page 36/41
Original issue
Oct.2012
Service Manual
One Plus
Model
18. Stitch length (Full-step version) --continued--
Adjustment without removing front and rear covers
1. Lay machine on its back and remove cap with small screw driver.
2. Loosen screw (A) with L-shaped 5 mm hex driver.
Turn screw (B) in either direction with minus screw driver and confirm whether adjustment is
correctly done after setting up machine in position. Repeat this process until desired feed
balance is obtained.
* Turn the screw (B) clockwise to adjust reverse stitch
* Turn the screw (B) counter clockwise to adjust forward stitch
B
To Next Page
