Singer One Plus - Page 4

Page 4/41
Original issue
Oct.2012
Service Manual
One Plus
Model
1. Disassembling of covers –continued--
(2) Bottom side
Remove a screw on front cover.
Remove a screw inside of access
hole of front cover.
Don’t remove screws above and
below the access hole
Remove cap for fine adjustment on assembly.
