3.3. Device use
The display (6) and the MENU (2), UP (3), DOWN (4) and ENTER (5) buttons are used to set the operating
modes.
- MENU (2): selection of main menu items / return to main menu level.
- UP (3) and DOWN (4): move up one menu level / change settings.
- ENTER (5): select option / confirm setting.
Overview of setting options for operation mode
3.3.1. CON.LED-100
No.
Display
Function Description
1
d001
Address code
（
001
－
512
）
2
8Ch
4Ch
8
、
4 channel selection
3
Au01
------
Au08
Au09
Au10
So01
So02
Au01- Au08 Fixed colour selection
Au09 Jump
Au10 Gradient
So01 Sound 1
So02 Sound 2
4
St00
St01
------
St16
St00 No strobe
St01-St16 Strobe from slow to fast
5
SP00
SP01
------
SP16
SP00
SP01-SP16 Auto speed from slow to fast
6
r255
Red colour selection
（
000
－
255
）
7
G255
Green colour selection
（
000
－
255
）
8
b255
Blue colour selection
（
000
－
255
）
9
u255
White colour selection
（
000
－
255
）
8-channel DMX mode:
No.
Function
Description
1CH
Total dimming
R;G;B;W total dimming, linear dimming, from dark to bright
2CH
R dimming
R dimming, linear dimming, from dark to bright
3CH
G dimming
G dimming, linear dimming, from dark to bright
4CH
B dimming
B dimming, linear dimming, from dark to bright
5CH
W dimming
W dimming, linear dimming, from dark to bright
