2.Indicator light and keys introduction
The product has four indicators: network indicator (blue), point indicator (green), touch indicator
(red), relay indicator (red), relay indicator (red); network indicator, touch indicator and timing
indicator can be turned off through app;
2.1 Network indicator lamp status (blue)
Blue indicator light：Network status indicator lamp
1. not connected router: bright 1S out 0.1S so reciprocating;
2. link router but not connected: flash once, flash once so repeated;
3. Touch pairing mode: quickly flash 4 consecutive times and then wait for 1S to reciprocate;
4. AP pairing mode: red light keeps flash;
5. networking success: the red indicator light is always on;
2.2 Click on the indicator light (green)
When the point function is turned on, the green indicator is on; when the point function is turned
off, the green indicator is off;
2.3 Timed indicator lamp (red)
When the product synchronizes with the Internet, the red indicator is on; when the product and the
Internet fails, the red indicator goes off;
2.4 Relay indicator lamp (red)
When the relay is engaged, the red indicator is on; when the relay is off, the red indicator is off;
2.5 Keybutton function
Short press: used to switch the working status of the relay;
Five seconds long: Put the product into the pairing state
