4
SAFETY INSTRUCTIONS
Every SIP pressure washer is carefully packed after assembly; On receiving the pressure
washer, check that it has not been damaged during transportation. If the pressure
washer is damaged, inform your distributor immediately, and, do not put the pressure
washer into operation until the damage has been repaired or the item replaced.
Before starting or servicing the pressure washer, read and understand all instruc-
tions. Failure to follow safety precautions or instructions can cause equipment
damage and/or serious personal injury; Retain all manuals for future reference.
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
Poisonous Fumes: Indicates a risk of possible inhalation of harmful fumes if
care is not taken.
Flammable: Indicates possible risk of combustion if care is not taken.
Hot Surfaces: Indicates risk of possible burning due to hot surfaces creat-
ed during normal operation.
Important: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the pres-
sure washer.
25
PARTS LIST
PUMP
Ref. No. Description SIP Code Ref. No. Description SIP Code
1. Filler bung PW08-00265 24. Nut PW08-00288
2. O-ring PW08-00266 25. Filter PW08-00289
3. Pump casing PW08-00267 26. Thermostatic valve PW08-00290
4. Oil seal PW08-00268 27. Thermostatic valve cap PW08-00291
5. Bearing PW08-00269 28. Bolt (M8 x 50) PW08-00292
6. Swash plate PW08-00270 29. O-ring PW08-00293
7. Bearing PW08-00271 30. Water return valve PW08-00294
8. Circlip PW08-00272 31. Spring PW08-00295
9. Spring seat PW08-00273 32. Vacuum nozzle PW08-00296
10. Spring PW08-00274 33. O-ring PW08-00297
11. Pin PW08-00275 34. O-ring PW08-00298
12. O-ring PW08-00276 35. Vacuum valve PW08-00299
13. Pump cover PW08-00277 36. Connector PW08-00300
14. Oil seal PW08-00278 37. Bracket PW08-00301
15. Gasket PW08-00279 38. Steel ball PW08-00302
16. Low pressure seal PW08-00280 39. Circlip PW08-00303
17. Spacer PW08-00281 40. Overflow valve PW08-00304
18. O-ring PW08-00282 41. O-ring PW08-00305
19. O-ring PW08-00283 42. Pin PW08-00306
20. Washer PW08-00284 43. Water outlet base PW08-00307
21. High pressure seal PW08-00285 44. Bolt (M5 x 30) PW08-00308
22. Pump head PW08-00286 45. Snap ring PW08-00309
23. Connector PW08-00287 46. Connector PW08-00310
