6
buildings to allow correct air flow.
Always connect the water inlet to an adequate supply with enough flow and pres-
sure; such as mains water supply.
Only connect the pressure washer to a cold water supply; never connect to a hot
water supply.
This pressure washer was not designed to ‘suck’ water from a barrel of water, or simi-
lar.
When not in use, always ensure that the pressure washer is fully drained of any wa-
ter and stored in a warm environment to protect it from frost damage.
Never direct the flow of water at other persons or animals.
Never direct the flow of water at electrical or electronic items.
Never direct the flow of water towards the pressure washer itself.
Do not stand or sit on the pressure washer, it was not designed for this purpose.
Never run the pressure washer without a clean water supply connected to it.
Never run the pressure washer for more than 3 minutes without depressing the trig-
ger.
Understand the operating environment; Before each use the operator should as-
sess, understand and where possible reduce the specific risks and dangers associ-
ated with the operating environment. Bystanders should also be made aware of
any risks associated with the operating environment.
SAFETY INSTRUCTIONS….cont
Caution: Anyone who operates this pressure washer should read and
fully understand all of the instructions and warnings in this manual.
Hot Surfaces: During normal operation certain parts of this pressure washer will
become hot. Always stay alert and be aware of hot components / surfaces.
Allow the engine to cool before attempting to move, clean or maintain the
pressure washer.
Poisonous Fumes: Exhaust fumes produced during normal operation
are poisonous. Do not operate this pressure washer in enclosed areas.
Always wear eye protection when using or maintaining the pressure
washer. Close bystanders should also wear adequate eye protection.
23
PARTS LIST
MAIN UNIT
Ref. No. Description SIP Code Ref. No. Description SIP Code
1. Bolt (M6 x 40) PW08-00320 17. Handle cover PW08-00336
2. Front foot PW08-00321 18-22. Nozzle set 72809
3. Nut (M6) PW08-00322 23. Rear cover PW08-00337
4. Frame PW08-00323 24. Front cover PW08-00338
5. Washer PW08-00324 25. Screw (M5x12) PW08-00339
6. Wheel PW08-00325 26. Tool box PW08-00340
7. Wheel clip PW08-00326 27. Screw PW08-00341
8. Washer PW08-00327 28. Hose PW08-00342
9. Axle PW08-00328 29. Filter PW08-00343
10. Knob PW08-00329 30. Bolt (M8 x 25) PW08-00344
11. Washer PW08-00330 31. Inlet connector PW08-00345
12. Bolt (M8 x 50) PW08-00331 32. Pump PW08-00346
13. Frame bung PW08-00332 33. Key PW08-00347
14. Pistol PW08-00333 34. Engine PW08-00348
15. Lance PW08-00334 35. Nut M8 PW08-00349
16. Handle PW08-00335 36. Bolt (M8 x 34) PW08-00350
