MACHINE
PART
ITEM
MAT.
CNC
DWG BY
APP. BY
DATE
DATE
QTY.
DEPT.
SIPROMAC
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
DEPT. TOL.
USINAGE
TOLERIE
SOUDAGE
METRIC
± 0.1
±
0.5
±
0.
5
INCH
± 0.004"
±
0.020"
±
0.020"
N.T.S.
NO.
005B0481
S.L.
1
M-(M)
300D & 350D
COVER ASSEMBLY
14-02-06
005B0481
LET. MODIFICATION
DATE
INT.
10
4
7
6
3
ITEM PART # DESCRIPTION QT.
1 002C0392 PLEXI COVER 1
2 004A0021 COVER HINGE ASSEMBLY 1
3 051-0740 WASHER 1/4" FLAT S/S 12
4 051-0255 BOLT 1/4-20 x 1-3/4" HEX SS 4
5 001A2919 WASHER 0.381``ID X 1.062``OD X 3 4
6 051-0581 NUT 1/4"-20 NYLON LOCK S/S 4
7 051-0288 BOLT 1/4-20 x 3 1/2" S/S 4
8 076-0010 "O" RING 1/4" x 3/8" x 1/16" 4
9 002-0026 UPPER SEAL BAR SPACER 4
10 004B0173 UPPER SEAL BAR PRE-ASS`Y 2
11 179-0005 NEOPRENE SPONGE 3/8" O.D. 2042mm
(6.7')
1
12 002-0024 HINGE BLOCK 2
13 051-0232 SCREW 1/4-20x 1-1/4"SKT CAP SS 4
14 051-0580 NUT 1/4"-20 S/S 4
15 058-0030 NYLON SPACER 3/8IDx3/4ODx1/16 4
2
1
5
11
9
3
15
12
14133
