*The phone number shown above
may differ from the one shown on
your Onyx. All numbers are valid.
You can follow either the general activation and subscription process or use the on-board
activation guide to activate your Onyx and subscribe to the XM service.
General activation and subscription process:
A. Make sure your Onyx is turned on, receiving the
XM signal, and tuned to XM channel 1 so that you
can hear XM audio.
B. Make a note of your XM Radio ID. You can find it
by selecting Radio ID in menu items, by tuning to
channel 0, on a label on the bottom of the gift box,
and on the label on the back of your Onyx.
NOTE! The XM Radio ID does not use
the letters I, O, S, or F.
C. To subscribe:
•Online: Go to www.siriusxm.com/activatenow to access or set up an online
account, subscribe to the service, and activate your Radio.
OR
•By phone: Call 1-866-635-2349.
Activation usually takes 10 to 15 minutes after you have completed the subscription process,
but may take up to an hour. We recommend that your Radio remain on until subscribed. Once
subscribed, the Radio will receive and you can tune to the channels in your subscription plan.
Press or to tune to other channels, and or to browse the different categories of
channels. Learn what all the buttons do in the panel below.
Activation guide:
For your convenience, Onyx has an on-board activation
guide. You can activate your radio and subscribe to the XM
service by using this guide, where you will be guided step-by-
step through the subscription process. To access and use the
guide, simply follow these steps:
A. Turn Onyx on and press the menu button.
B. Activate Radio will be highlighted. Press the Select
button.
C. Follow the directions on each successive screen
until you complete the subscription process.
866-635-2349
siriusxm.com
1 XM Preview
Menu
Activate Radio
Radio ID
FM Settings
JUMP Settings
Brightness
6 ?
What’s in the Box?
7
2
34567890
direct
jump
FM
menu
1
Decide on one of the following in-box audio connection options. Refer to “Step 6: Connect the Audio” on
page 35 of the Onyx User Guide (with Vehicle Kit) for additional audio connection options, such as a
cassette adapter or the FM Direct Adapter (FMDA) (both sold separately).
Option 1: Best: Use the provided Aux In Cable, if your vehicle’s stereo system has an auxiliary input jack.
A. Plug one end of the cable into the green
AUDIO connector on the PowerConnect
Vehicle Dock and the other end into the
auxiliary input jack on the vehicle’s stereo
system.
B. Turn on your vehicle’s stereo system and
set it to play from the auxiliary input
source.
C. You should hear XM channel 1 through your vehicle’s stereo system.
D. Attach the dock to the mount. Go back to step 1 “Find a Location for Onyx
and Mount It” on the opposite side and finish installing the Dash or Vent
Mount. Then the installation is complete.
TIP! Refer to your vehicle’s owner’s manual to find the location of the auxiliary input
jack, or consult the vehicle dealer.
Option 2: Good: Use the PowerConnect feature of Onyx. PowerConnect plays the XM audio through your
vehicle’s FM radio.
A. Find and make a list of all available FM channels in your area that are not being used by an FM radio
station.
B. Pick the first FM channel on your list. Tune your vehicle’s FM radio to this FM channel.
NOTE! If you are using the Vehicle Dock from the Universal Xpress Car Kit instead of
the PowerConnect Vehicle Dock which came with your Onyx, you will have to
disable AUX Detect. Refer to “Using the Vehicle Dock From the Universal Xpress Car
Kit” on page 88 of the Onyx User Guide (with Vehicle Kit), and complete the
additional instructions before continuing with the next step. The audio connection
will be through your vehicle’s FM radio, but it is not PowerConnect.
C. Set your Onyx to transmit on the same FM channel that you have selected on
your vehicle’s FM radio:
i. Press menu and then press to scroll to and highlight FM Settings. Press
the Select button.
ii.
FM Channels will be highlighted. If it is not highlighted, press to scroll to
and highlight FM Channels. Press the Select button.
iii. Press
to scroll to and highlight FM2. Press the Select button.
iv. Press and to tune in steps of .2, or press and to tune in steps of
1 to select the available FM channel you have chosen. Press the Select
button to select the FM channel.
v. Start Using will be highlighted. P
ress the Select button.
vi. The selected FM channel will be confirmed on the display screen.
D. You should hear XM channel 1 through your vehicle’s FM radio. If you are
satisfied with the sound quality attach the dock to the mount. Go back to
step 1 “Find a Location for Onyx and Mount It” on the opposite side and finish
installing the Dash or Vent Mount. Then the installation is complete.
E. If you are not satisfied, move to the
next FM channel on your list and
repeat the process. Continue until you
have found an FM channel with which
you are satisfied.
Connect the Audio
CAUTION: Do not attempt to install, activate, or adjust any of the
setting options described in this Quick Start Guide unless your
vehicle is parked in a safe location.
2
34567890
direct
jump
FM
menu
1
Onyx Radio
PowerConnect Vehicle Dock
Magnetic Mount
Antenna
Antenna & Dash Mount
Alcohol Preparation Pads
PowerConnect Power Adapter
Aux In Cable
Dash Mount
Trim Rings
Vent Mount
and Extended
Vent Clamps
Trim Ring Removal
Tool
Cable
Routing Adapter
Direct Button
Press first before
entering the channel
number, to directly
tune to a channel.
Power Button
Press to turn Radio on
and off.
Left and Right Buttons
Press to search for
channels by category.
Up and Down Buttons
Press to preview and tune
to channels through the
channel lineup; also press
to scroll through lists and
highlight menu items.
Menu Button
Press to access
advanced features and
configuration options;
in configuration options,
press and hold to return
to main display screen.
Select Button
Press to confirm
selection of highlighted
items in a menu or list.
FM Button
Press to access and
cycle through FM
presets.
Jump Button
Press to directly access
traffic and weather for
the city of your choice;
or press it to go back
to the previous channel
to which you were
listening.
Number Buttons
Press to tune to
a stored favorite
channel, press and
hold to store a favorite
channel; also enter a
channel number.
Trim Ring
Changeable
decorative
Trim Ring.
Tom Petty
I Should Have Known It
28 The Spectrum
Antenna Signal
Strength
Channel Number
Channel Name
Artist Name
or Talk Show Host
or Sports Teams/Score
Song/Program Title
or Talk Show Schedule
or Game Time/Game Details
When listening to a channel, information about the channel and what is currently playing is
displayed.
Onyx Button Functions
Onyx Main Display
Subscribe
2
34567890
direct
jump
FM
menu
1
99.3
MATCH FM CHANNELS
Edit FM Channel 2
99.3 FM
and Select to confirm
Press arrow keys to tune
FM Channel 2
Start Using
Edit Channel
FM Channels
current
FM 1
FM 2
FM 3
FM 4
FM 5
97.9
_ _ _
_ _ _
_ _ _
_ _ _
Self installation instructions and tips are provided for your convenience. It is your
responsibility to determine if you have the knowledge, skills and physical ability
required to properly perform an installation. SiriusXM shall have no liability for
damage or injury resulting from the installation or use of any SiriusXM or third
party products. It is your responsibility to ensure that all products are installed
in adherence with local laws and regulations and in such a manner as to allow
a vehicle to be operated safely and without distraction. SiriusXM product
warranties do not cover the installation, removal or reinstallation of any product.
Sirius XM Radio Inc.
1221 Avenue of the Americas
New York, NY 10020
1.866.635.2349
siriusxm.com
© 2012 Sirius XM Radio Inc.
XDNX1VKQSG 121011a
QUICK START GUIDE
Dock & Play Radio
with Vehicle Kit
