SIRS NAVIGATION LTD
COMPONENT MAINTENANCE MANUAL
DETAILED PARTS LIST
FIG.
ITEM
PART NUMBER AIRLINE
PART
NUMBER
I
N
D
E
N
T
NOMENCLATURE
USAGE
FROM
TO
UNITS
PER
ASSY.
1-
-1A KCA0101C 1 OBSOLETE A -
-1B KCA0102C 1 OBSOLETE B -
-1C KCA0102W 1 OBSOLETE C -
-1D KCA0107W 1 OBSOLETE D RF
-1E KCA0109W 1 OBSOLETE E RF
-1F KCA0110W 1 OBSOLETE F RF
-1G KCA0101W 1 COMPASS (MOD 02) G RF
-1H KCA0104W 1 COMPASS (MOD 02) H RF
-1J KCA0104FY 1 COMPASS (MOD 02) J RF
-1K KCA0105W 1 COMPASS (MOD 02) K RF
-1L KCA0106W 1 COMPASS (MOD 02) L RF
-1M KCA0112W 1 COMPASS (MOD 02) M RF
-1N KCA0113W 1 COMPASS (MOD 02) N RF
-1P KCA0113FY 1 COMPASS (MOD 02) P RF
-1Q KCA0114W 1 COMPASS (MOD 02) Q RF
-1R WL1001KCA1 1 COMPASS (MOD 02) R RF
10 CE2-A124 2 BELLOWS G-K
M-R
RF
10A CE2-A124G 2 BELLOWS (GREY) L RF
20 CE2-A122 2 RETAINING CLIP G-K,
M-R
1
20A CE2-A122G 2 RETAINING CLIP (GREY) L 1
30 910012 2 SCREW G-R 1
40 920006 2 NUT G-R 1
50 CE2-44 2 PACKING PIECE G-R 1
60 CE2-110 2 GASKET G-R 1
70 CE2-109 2 COMPENSATING RING G-R 1
80 CE2-A126 2 STEM ASSEMBLY G-R 1
90 910210 2 SCREW G-R 2
130 CE2A127 2 CARD ASSEMBLY G-H
K-N
Q-R
1
PAGE 10003
APR 10/03
34-25-21
