2. 規格說明 ( 表 1)
2. Specication(Tab.1)
機型 Model 700L
最高縫速 Max Stitch Speed 7500rpm / 7500rpm
噪音值 Noise Level 82 分貝以下 under 82 dB
縫距 Stitch Length 4 / 5 / 6 mm
針棒行程 Stroke of the needle bar 24.3 ±0.2 mm
押具揚程 Presser Foot Lift 5.5mm
押具壓力 Presser Foot Pressure 5kg
送具高度（凸出針板面）
Feed Dog Height (over the plate)
0.7~0.9mm
使用針 Needle for Use DCX27
送具傳動方式 Feed Dog Transmission 偏心輪、連桿 Eccentric, Connecting Rod
送具齒寬度
Teeth Width of the Feed Dog
1.6mm
縫目調整裝置 Stitch Adjusting D
evice 按鈕調整 Button Adjustment
押具裝置 Presser Foot Device
彈簧式、旋紐調整式
Spring Type, Knob Adjustment Type
加油方式 Oil Filling
儲油槽儲存方式，毛氈、棉線毛細管自動供油
Oil ank storage type. Automatic oil supply by Oil felt,
otton thread capillary action.
回油方式 Oil Return Solution 偏心泵浦 Eccentric Pump
使用油 Oil for Use
提供專用油 (MOBIL #10)
Provide Specific Oil (MOBIL #10)
表 1 / Tab. 1
