P-39
顯示速控器電壓
display the volt of
speed controller
14-1010
中點電壓
195
Neutral
point volt
顯示當前速控器電壓 0—
1024，相當於 0-5V
Display the current speed
controller volt 0-1024, it is
equal 0-5V
P-40
顯示直流母線電壓
display DC buses
voltage
60-500V 320v
當電壓高於 395 會報警，
(直流母線電壓/1.414=交
流母線電壓)when the volt
is higher than 395V will
alarm,(DC buses volt/1.414
= AC buses volt )
P-41
過壓保護開關
overload protection
switch
0:關閉 1:開啟
0: close 1:start
1
設為 0 關閉過壓報警，設
為 1 打開報警，當直流母
線電壓超過 395V 時，報
警 Er16，電機自動停止運
行，報警後當電壓低於
385v 電機可再次運行 set
“0” is close the overload
alarm, set “1” is open the
alarm, when DC buses voltage is
over 395 V , will display Er16,
the motor will stop automatic,
when volt is lower 385V, the
motor can run.
四、一般故障處理：Common faults and treatments
錯誤碼
Error code
錯誤內容
Error content
錯誤問題的多種可能
Several possible error problem
Er01
找不到停針位
Can’t find the
needle position
1.手輪靠的不夠近間隙在 2.5mm 內
2.九針插頭接觸不良
3.電機霍爾壞，要更換電機
4.手輪上的磁鐵掉落
1. The hand wheel is not close, clearance within 2.5 mm
2. Nine plug contact undesirable
3. Motor holzer bad, to replace the motor
4. The hand wheel magnet in the loss
Er02
開機沒有檢測
到調速器
Not detected
boot speed
regulator
1.調速器插頭沒有插
2.調速器線斷了或接觸不良
1. Speed control device without plug
2. Speed wire is broken or contact undesirable
Er03
電機霍爾或相
位線錯誤
Motor holzer or
phase error
1.九針插頭接觸不良
2.電機沒有安裝好，參照圖 A
3.霍爾壞
1. Nine hole plug contact undesirable
2. The motor doesn’t pack good
3. Holzer is bad
