Parts packing list
Code Description Qty
11 Hex-head screw M6 x 47mm 2
13 Washers Ø20*Ø8.5*1.5 12
15 Nut M8 6
16 Nut M6 2
27 Washer Ø16*Ø6.5*1.0 4
38 Hex-head screw M8 x 25mm 2
40 Hex-head screw M8 x 50mm 2
41 Square end cap 1
43 Hex-head screw M8 x 38mm 2
48 End cap Ø27*Ø13.5 2
49 Pivot arm ring 2
Double ended wrench 2
M 12 / M 14
Phillips Screwdriver 1
Note:
These parts are packed separately and will be required for assembly. Please check that all parts
are present before starting assembly.
All other parts are premounted.
Remove the packaging and place all parts within easy reach. Use the parts list to help you identify
the individual parts.
Now proceed as follows to assemble
