Parts list
Code Description Qty
1 Front U-frame 1
2 Rear U-frame 1
3 Adjustable arm 1
4 Table frame 1
5 Pivot arm with position openings 2
6 Adjustable instep frame 1
7 Steel Heel Holder Bracket 4
8R Right Folding Arm 1
8L Left Folding Arm 1
9 Bars 1
10 Hex-head screw M8 x 23mm 2
11 Hex-head screw M6 x 47mm 2
12 Cross-head screw M6 x 30mm 4
13 Washers Ø20*Ø8.5*1.5 16
14 Cross struts 1
15 Counternut M8 8
16 Counternut M6 6
17 Small spring button 1
18 Large spring button 1
19 Safety hook (karabiner) 2
20 Rubber mount 1
21 Round end cap 2
22 Foot bar end cap 2
23 Spring 1
24 Square end cap 1
25 Round end cap 4
26 Guide bush for table frame 2
27 Washer Ø16*Ø6.5*1.0 8
28 End cap 1
29 Bar grip 2
30 Knob 1
31 Rubber Heel Holder 4
32 Nylon strap 1
33 Nylon strap 1
34 Strap buckle 1
35 Nylon lining / table 1
36 Foam grip 2
37 Protective cover 2
38 Hex-head screw M8 x 23mm 2
39 Foot rest 1
40 Hex-head screw M8 x 50mm 2
41 Square end cap 2
42 Spring washer 1
43 Hex-head screw M8 x 38 mm 2
44 Length adjustment scale 1
45 Plastic bushes 1
46 Foam pad 1
47 Double-sided adhesive tape 1
48 End cap Ø27*Ø13.5 2
49 Pivot arm ring 2
