Sit 440 D3 - Page 4

SIT La Precisa
Viale dell'Industria 31/33 35129 PADOVA - ITALY
Tel. 049/8293111 - Fax 049/8070093 - Telex 430130 SITEC I
9.955.771 - R00 GRAPHIC DESIGN BY START - PD - ITALY
DIMENSIONS
15
52,5
103,5
51
38,5
77
45
DESCRIPTION
3 Pilot outlet
4 Thermocouple connection
5 Gas inlet
6 Gas outlet
1 Button connected to the thermo-
electric safety device
2 Adjustment screw for gas flow to
the pilot
1
2
3
4
5
6
