Focus 2.0 ASSEMBLY INSTRUCTIONS
•
Swivel-Tilt or Basic Mechanism (1)
•
5
⁄16" × 1½" Screw (4)
•
0.317" Washer (4)
•
Enhanced Synchro Mechanism With
Optional Seat-Depth Adjustment (1)
•
5
⁄16" × ¾" Screw (3)
•
0.317" Washer (3)
Parts
Swivel-Tilt
Mechanism
Enhanced Synchro
Mechanism
ENHANCED SYNCHRO
SWIVEL-TILT OR BASIC
Basic
Mechanism
Parts: Base
Cylinder Base Assembly Foot Ring
•
Base Assembly (1)
•
Cylinder (1)
•
Foot Ring (1, Optional for Stool)
5
⁄16" × 1½" Screws0.317" Washers
⁵
⁄
₁₆
" × ¾" Screws
0.317" Washers
