Sitron CF12 AC - CF12 Wiring Diagrams - Nylon Enclosure; CF12 AC Wiring Diagram (Nylon); CF12 DC Wiring Diagram (Nylon)

06
Wiring Diagram
Standard Connection w/
2 meters of Cable
+
_
Bargraph (B1)
Bargraph (B1)
Adjust (P1)
Adjust (P1)
Central LED (L1)
(Red/Green)
Central LED (L1)
(Red/Green)
Adjust
CF 12 DC
Adjust
Red
White (NO)
Green and
Yellow
or solid Yellow
Green (common)
Blue (NC)
Black
Power
Supply
Contacts
Ground
CF 12 AC
2000mm
1
2
Connector
12mm
NO or NC
contact
2000mm
1
2
Connector
12mm
contact
NO or NC
Nylon Enclosure (N1)
M12 Connector Optional
M12 Connector Optional
1
2 - Power Supply (-)
3 - Ground
4 - NO Contact
5 - Common
6 - NC Contact
- Power Supply (+)
1
2 - Power Supply
3 - NO Contact
4 - NC Contact
5 - Common
- Power Supply
1
2 - Power Supply (-)
3 - NO Contact
4 - NC Contact
5 - Common
- Power Supply (+)
1
1
5
5
2
2
3
3
4
4
