Locate the arrow on the wall of the tire. If it doesn’t
have an arrow, you can add the wheel in any direction.
With the arrow pointing forward, insert the wheel into
the fork dropouts. The axle nuts will fall inside the
fork entry. Tighten nuts on both sides with a 15mm
crescent or socket wrench and verify wheel is sitting
in center of the fork. You can now put the kickstand
down to hold the bicycle up.
03
Insert the handlebar stem through the lock nut cap
and into the headtube. Line up the stem, frame, and
front wheel, then tighten. the handlebar stem bolt.
04
Straightening the stem, frame, and front wheel will ensure
that your handlebars and wheel are properly aligned.
NOTE
FORK DROPOUTS
AXLE NUTS
FRONT
WHEEL
HANDLEBAR
STEM
HEADTUBE
LOCK NUT CAP
MULTI-TOOL HANDLEBAR
LOCK NUT CAP
