WE STRIVE FOR PERFECT, ALTHOUGH IT ’S NOT ALWAYS POSSIBLE, WE NEVER LEAVE A RIDER BEHIND.
(2) WASHERS, NUT
AND LONG BOLT
( pre-installed)
FRONT FENDER
+ STRUT
Order from front to back:
LONG BOLT, WASHER, FORK, FENDER TAB, WASHER, NUT.
Remove the screws from the fork eyelets.
NOTE
PHILLIPS
SCREWDRIVER
10MM
MULTI-TOOL
11
Align the fender struts with the eyelets on the fork, so that
the fender tab is pointing upwards. Slide the fender up
through the back of the front tire.
Use a Phillips head screwdriver and the 10mm multi-tool
to remove then install the fender tab screw and nut.
FENDER TAB
To Next Page
