WE STRIVE FOR PERFECT, ALTHOUGH IT ’S NOT ALWAYS POSSIBLE, WE NEVER LEAVE A RIDER BEHIND.
Untighten the clamp with a 9mm wrench/socket a quar-
ter turn at a time until you are able to tap the derailleur
slightly up and down without it falling completely down
the seat tube. While still pulling the cage forward, grab
a penny and place it above the largest chainwheel. Ad-
just the height of the derailleur cage so it sits above the
penny. With a mallet/hammer and the allen key, you can
slightly tap the derailleur up or down based on its original
position. Reference the bottom right image as an exam-
ple. Now tighten the cage in place with a 9mm wrench/
socket.
05
9MM
MULTI-TOOL
MALLET
OR HAMMER
2 PENNIES
1
2
3
4
