Trim Gauge – If equipped
The trim gauge indicates bow position of the boat in the water. This is achieved by changing the angle of the
outboard motor.
Sonar Fishfinder and Depthsounder – ZX, SX Models
Refer to the fishfinder and depthsounder operations manual.
Water Pressure Gauge – If equipped
The water pressure gauge monitors the cooling system pressure of the engine. Refer to your outboard motor
owner’s manual for information.
Voltmeter – If equipped
The voltmeter indicates voltage to the batteries from the charging system.
Tachometer
The tachometer registers engine speed in revolutions per minute (RPM). Refer to your outboard motor opera-
tor’s manual for the correct operating range of the engine.
