Battery Connections
Figure 8-2
Figure 8-2 shows a typical 12, 24, and 36 volt connection.
12 VOLT
36 VOLT
24 VOLT
BATTERY #2
BATTERY #1BATTERY BATTERY #2
BATTERY #1 BATTERY #3
9343-016
