DEEPWATER BOATS
5-3
1. Tilt Steering Latch
2. Power Switch
3. Fuel Gauge
4. Trim Gauge
5. Speedometer
6. Engine Warning Light
7. Fishfinder/Depthfinder
8. Steering Fluid Fill Cap
9. Engine Low Oil Pressure Warning Light
10. Tachometer
11. Water Pressure Gauge
12. Voltmeter
13. Switch Panel
14. Aerator
15. Starboard Livewell – Recirculation
16. Port Livewell – Recirculation
17. Starboard Livewell – Fill
18. Port Livewell – Fill
19. Horn
20. Fuel – Fore/Aft
21. Navigation Lights
22. Courtesy Lights
23. Bilge Pump
24. Ignition Switch
25. Engine Stop Switch and Cord (Lanyard)
26. 12 Volt Accessory Port – except ZX1775SC
27. Bilge Switches
28. Tilt Switch
29. Remote Control
