5-14
DEEPWATER BOATS
Battery Charging System – ZX2050, ZX1950
The battery charging system allows you to charge the batteries without removing the batteries from the boat.
Refer to the manufacturer’s literature for operating instructions.
Make sure all accessories and outboards are in the OFF position when connecting to the power source and
charging the batteries.
Livewell System
OPEN/CLOSED Selector Switch – Livewell System
Figure 5-10
9343-021
CLOSED
OFF
OPEN
AERATOR
FILL
CLOSED
OFF
CLOSED
AERATOR
FILL
On Plane
At Rest
On Plane
At Rest
Do not charge your batteries in the boat unless your boat is equipped with an
onboard charging system.
WARNING
Section 5_2008.qxd:Section 5_horiz.qxd 8/1/07 4:57 PM Page 5-14
