5SKF TMDS 6
26 Locknut Spanner TMHN 7 1
27 Aluminium Heating Ring TMBR NU 216EC 1
28 Feeler Gauge 729865 A 1
29 Hook Spanner HN 18–20 1
30 Quick Connections Nipple 729100 1
31 Mounting Fluid LHMF 300/5 1
32 Dismounting Fluid LHDF 900/5 1
33 Dial Indicator TMCD 5P 1
34 Hook Spanner HN 17 1
4. Required bearings and accessories
(not included with TMDS 6)
Bearing Quantity Accessory Quantity
22320 EK/C3 2 H 2320 1
22318 EK/C3 1 AHX 2318 1
6006 1 KM 17 1
6315 1 MB 17 1
6318 1 H 209 1
1209 EKTN9/C3 1 KM 20 2
NU 216ECP 1 MB 20 2
Note: Demonstration Unit TMDS 6 includes Turning Table, Shafts and
Accessories (1 to 18) as shown in section 2.
Demonstration Unit TMDS 6/1 includes Turning Table, Shafts,
Accessories and Tools (1 to 34) as shown in section 2 and section 3.
Demonstration Unit TMDS 6/1US is the same as TMDS 6/1 except the
TIH 030m/220V is replaced by TIH 030M/110V.
Warning: Never dismount a bearing from a tapered seating by means of the Oil injection
Method without having an hydraulic nut or an SKF locking nut screwed onto the
shaft end. Make sure that the bearing bore, as well as the shaft seating are clean
and slightly coated with oil before mounting.
