Ski-Doo Mach Z User Manual

Section 01 SERVICE TOOLS AND SERVICE PRODUCTS
Sub-Section 01 (SERVICE TOOLS)
I
Piston circlip installer
A) (P / N 5290169 00)
m
o
B) (p / N 2908770 16)
m
A:
Piston
circlip
A01B1P4
APPLICATION
I A) Allenginesexcept 670.
I B) 670 engines.
Piston pin / connecting
m
o
rod bearing centering tool
(P/ N 5290091 00)
o
NOTE : New diameter is
9.65 mm (0.380”).
I AOIBIRA
APPLICATION
All engines.
ENGINE (Optional Service Tools)
Ring compressor
A)(P/N4208760 90)
m
~A
(62 mm)
B)(p/N4208769 74)
m
o
(69.5 mm)
Q (p/N 4208769 70)
m
O*
(72 mm)
D) (p
/ N 420876972)
m
t
(76 mm)
E) (p/N 4208769 75)
m
8:
(67.5 mm)
m
F) (p/N 5290308 00) ●
(78 mm)
A01B1T4
APPLICATION
A) 377 engines.
B) 467 engines.
C) 503, 253 and 536 engines.
D) 582, 583 and 643 engines.
E) 447 engines.
F) 670 engines.
Magneto coil centering o ●
m
ring
(P/ N 4208769 22)
A01B1V4
APPLICATION
All engines with Nippondenso
CDI (160 W).
Seal protector sleeve
${~, 4209779 IO)
Rn
t
(p/ N 4202769 00)
m
(MAG)
D
AOOCOD4
APPLICATION
247 engine.
Engine seal pusher
m
(P/ N 4209779 20)
AOOCOV4
APPLICATION
247 engine.
Polyamid ring pusher
(p/ N 4202769 30)
Q“
AOOCOZ4
APPLICATION
247 engine.
01-01-5

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
