Section 03 TROUBLESHOOTING
Sub-Section 05 (SUSPENSION SYSTEM AND TRACK)
03-05-3
SYMPTOM HANDLE BAR IS DIFFICULT TO TURN.
CONDITION NORMAL USE.
Test / Inspection 1. Check position of front spring adjustment cams.
a. More pressure on the ground when cam increases spring preload.
Reduce front spring preload.
2. Check position of stopper strap.
a. More weight when stopper strap is short.
Lengthen front arm stopper strap.
3. Check position of front arm shock adjustment cam(s).
a. When spring tension is weak, more weight is transferred to the skis.
Increase spring preload.
4. Check condition of ball joints.
a. Corrosion restrains movement.
Lubricate or replace.
5. Check swing arm camber (liquid cooled models).
a. Too much ski leg inclination.
Adjust camber to 0° ± .5°.
SYMPTOM
THE SNOWMOBILE IS UNSTABLE (IT MOVES FROM LEFT TO RIGHT AND VICE
VERSA).
CONDITION NORMAL USE.
Test / Inspection 1. Check ski runner condition.
a. Worn or bent ski runners.
Replace ski runners.
2. Check ski alignment.
a. Improper ski alignment.
Align skis in order to obtain proper toe-out (opening) (to adjust, refer to section 08
STEERING system).
3. Check if bushings are too loose in steering system.
a. Bushings are too loose.
Replace.

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
