8
station (addresses as well as the service diagram of
the tool are listed on www.skil.com)
TROUBLESHOOTING
• The following listing shows problem symptoms, possible
causes and corrective actions (if these do not identify
and correct the problem, contact your dealer or service
station)
! switchoffthetoolanddisconnecttheplugbefore
investigatingtheproblem
★ Tool does not operate
- no power supply -> check power supply (power cable,
circuit breakers, fuses)
- plug not connected -> connect plug
- extension cord damaged -> replace extension cord
- on/o switch defective -> contact dealer/service
station
- worn carbon brushes -> contact dealer/service station
- defective motor -> contact dealer/service station
- blowing/vacuum tube not completely mounted ->
mount two-part blowing/vacuum tube
★ Tool operates intermittently
- on/o switch defective -> contact dealer/service
station
- internal wiring defective -> contact dealer/service
station
- impeller blocked by foreign object -> remove blockage
★ No/low blowing power
- selector switch in vacuuming mode -> set selector
switch in blowing mode
★ No/low vacuuming power
- selector switch in blowing mode -> set selector switch
in vacuuming mode
- collection bag is full/dirty -> empty/clean collection bag
- vacuuming opening clogged up or blocked by foreign
object -> remove blockage
ENVIRONMENT
• Donotdisposeofelectrictools,accessoriesand
packagingtogetherwithhouseholdwastematerial
(only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol 9 will remind you of this when the need for
disposing occurs
NOISE/VIBRATION
• Measured in accordance with EN 60335 the sound
pressure level of this tool is 80 dB(A) and the sound
power level 100 dB(A) (standard deviation: 3 dB), and the
vibration 2.8 m/s² (triax vector sum; uncertainty K = 1.5
m/s²)
• Measured in accordance with 2000/14/EC the
guaranteed sound power level LWA is lower than 103
dB(A)
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60335; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintained accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protectyourselfagainsttheeffectsofvibration
bymaintainingthetoolanditsaccessories,
keepingyourhandswarm,andorganizingyour
workpatterns

Aspirateur-souffleur
dejardin 0792/0796
INTRODUCTION
• Cet outil a été conçu pour souer/rassembler et aspirer/
broyer les feuilles sèches et autres déchets secs de
jardinage, notamment l’herbe et les branches
• Cet outil est uniquement destiné à un usage domestique
et n’est pas conçu pour être utilisé dans des lieux
humides
• Cet outil n’est conçu pour un usage professionnel
• Vériez que le conditionnement contient toutes les
pièces présentées dans le schéma 2
• Lorsque des pièces manquent ou sont endommagées,
veuillez contacter votre distributeur
• Lisezattentivementcemanueld’instructionavant
d’utiliserl’outiletconservez-lepourpouvoirvousy
référerultérieurement3
• Prêtezattentionauxconsignesdesécuritéetaux
avertissements;nepassuivrecesinstructionspeut
entraînerdesgravesblessures
CARACTERISTIQUES TECHNIQUES 1
ELEMENTSDEL’OUTIL2
A Tube inférieur de souage/d’aspiration
B Tube supérieur de souage/d’aspiration
C Bac récolteur
D Poignée de guide
E Bretelle
F Dispositif d’immobilisation du cordon d’alimentation
G Gâchette
H Commutateur pour sélectionner le mode de
fonctionnement
J Molette de réglage de la vitesse maximum (0796)
K Roue d’appui
L Fentes de ventilation
M Poignée principale
N Vis de xation 25 mm
P Vis de xation 50 mm
Q Ouverture d’aspiration
R Ouverture de souage
S Rail de rangement (visnonfournies)
