SKLZ.com
Legs (E)
On/Off Switch
AC Adaptor Plug-in
Rear Stability Bar
Adjustable
Distance Knob
Trajectory Lever Knob
Trajectory
Lever
Ball Catapult
Catapult
™
Base (A)
Spiral Ball Funnel Top (B)
Spiral Ball Funnel Bottom (D)
Spiral Ball Funnel
Mid-Section (C)
F – AC Adapter
