Use of the child seat in the front passenger seat
Applies to Taiwan
Fig. 15 Front passenger sun visor / label
Read and observe and on page 22 first.
No babies, infants or children are to be carried on the passenger seat.
This fact is also indicated by the label that can be found on the passenger's
sun visor » Fig. 15.
Child safety and side airbag
Fig. 16
Incorrect seated position of a
child who is not properly secured
– risk from the side airbag/Child
properly protected by safety seat
Read and observe
and on page 22 first.
The child must not be positioned in the deployment area of the side air-
bag » Fig. 16 -
.
There must be sufficient room between the child and the deployment area of
the side airbag to ensure that the airbag can provide as much protection as
possible » Fig. 16 -
.
WARNING
■
Children must never be seated with their head in the deployment area of
the side airbag – risk of injury!
■
Do not place any objects within the deployment area of the side airbags –
risk of injury!
Classification of child seats
Read and observe and on page 22 first.
Classification of child seats according to the ECE-R 44 standard.
Group Weight of the child Approximate age
0 up to 10 kg up to 9 months
0+ up to 13 kg up to 18 months
1 9 - 18 kg up to 4 years
2 15 - 25 kg up to 7 years
3 22 - 36 kg over 7 years
Use of child seats fastened with a seat belt
Read and observe
and on page 22 first.
Overview of the usability of child seats fastened with a seat belt on each of
the seats in accordance with the ECE-R 16 standard.
Group
Front passenger
seat
Rear seats
external
Rear seat
Centre
0
up to 10 kg
U U U
0+
up to 13 kg
U U U
1
9 - 18 kg
U U U
2
15 - 25 kg
U U U
3
22 - 36 kg
U U U
24
Safety
