Group
Size class of
the child seat
a)
Front passenger seat Outer rear seats Rear seat middle
1
9 - 18 kg
D
X
IL-SU
IUF
X
C
B
B1
A
2
15 - 25 kg
X IL-SU X
3
22 - 36 kg
X IL-SU X
a)
The size category is shown on the label attached to the child seat.
The seat is suited for installation of a -child seat with the “Semi-
Universal” approval. The “Semi-Universal” category means that the child
seat with the
-system is approved for your vehicle. Observe the list
of vehicles that comes with the child seat.
The seat is suitable for the installation of a
-child seat with the ap-
proval “Universal” and attachment with the
-system belt.
The seat is not fitted with
-system attachment points.
Attachment points of the
-system
Fig. 18
Anchor eyelets on the TOP
TETHER system
represents a fastening system, which restricts movements of the up-
per part of the child seat.
The anchor eyelets for attaching the belt for a child seat with the
-sys-
tem are located on the rear side of the outer rear seat backrests » Fig. 18.
IL-SU
IUF
X
WARNING
■
Always refer to the instructions from the manufacturer of the child seat
when installing and removing a child seat with the -system.
■
Only use child seats with the
-system on the seats with the lock-
ing eyes.
■
Only ever attach one belt from the child seat to a locking eye.
■
On no account should you equip your vehicle, e.g. mount screws or other
anchorage points.
26
Safety
