Head restraints - adjusting height
Fig. 53 Head rests: move up / move down
Read and observe
on page 69 first.
Adjustment of the head rest heights is the same in the front and rear.
Best protection is achieved if the top edge of the head rest is at the same level
as the upper part of your head.
Move upwards
›
Push the headrest in the direction of arrow
1
» Fig. 53.
Move downwards
›
Press the locking button
A
in the direction of the arrow
2
and
hold » Fig. 53.
›
Push the headrest in the direction of arrow
3
.
WARNING
With seats occupied, the respective head rests must be correctly set (may
not be in the bottom position) - there is a risk of fatal injury!
Note
For the sports seats, the head restraints are integrated into the front seat
backrests. This headrest cannot be adjusted in height.
Headrests - removing and installing
Fig. 54 Front head rests: removal / installation
Fig. 55 Rear headrests: removal / installation
Read and observe on page 69 first.
Front restraint
›
Pull the restraint out of the seat backrest as far as the stop.
›
Press the locking button
A
in the direction of arrow
1,
and pull the support
in the direction of arrow
2.
›
To re-insert the head restraint, push it far enough down in the direction of
arrow
3
into the seat backrest until the locking button clicks into place.
Rear restraint
›
Pull the restraint out of the seat backrest as far as the stop.
›
Press the locking button
B
in the direction of arrow
4
, while at the same
time using a flat screwdriver with a max. width of 5 mm to press the securing
button in opening
C
in the direction of arrow
5
.
›
Remove the restraint in the direction of arrow
6
.
70
