Electrically adjustable seats are protected by automatic circuit breakers, which
switch on again automatically after a few seconds after the overload has been
eliminated.
Bulbs
Changing bulbs
The relevant lamp must always be switched off before a light bulb is replaced.
12 Power supply of the self-diagnosis 7,5
13 Brake lights 10
14
Interior lighting, central locking system, interior lighting
(without central locking system)
10
15 Instrument cluster, steering angle sender, rear mirror 5
16 Air conditioning system 10
17
Heated windscreen washer nozzles
daylight driving lights
5
30
18 Right main beam 10
19 Left main beam 10
20 Right low beam, headlight range adjustment 15
21 Low beam on the left 15
22 Right parking light 5
23 Left parking light 5
24 Front window wiper, motor for wash pump 20
25 Air blower, air conditioning system, Climatronic 25
26 Rear window heater 25
27 Rear window wiper 15
28 Fuel pump 15
29
Control unit: Petrol engine
control unit: Diesel engine
15
10
30 Electric sliding/tilting roof 20
31 Not assigned
32
Petrol engine - injection valves
diesel engine - injection pump, control unit
10
30
33 Headlight cleaning system 20
No. Power consumer Amperes
34
Petrol engine: Control unit
diesel engine: Control unit
10
10
35
Trailer socket, power socket in the luggage compart-
ment
30
36 Fog lights 15
37
Petrol engine: Control unit
diesel engine: Control unit
20
5
38
Lighting of the luggage compartment, central locking
system, opening of the fuel filler flap, interior lighting
15
39 Hazard warning light system 15
40 Horn 20
41 Cigarette lighter 15
42 Radio, mobile phone 15
43
Petrol engine: Control unit
diesel engine: Control unit
10
10
44 Seat heaters 15
a)
For power consumers, e.g. the radio, which can be operated with the ignition switched off as
long as the ignition key is not withdrawn.
No. Power consumer Amperes
s2g8.b.book Page 195 Tuesday, April 7, 2009 8:53 AM
