Specifications
230V AC; 50Hz
45W (max.) / LNB switching +13/+18VDC 275mA MAX/22kHz
5kg (packed)
399mm x 295mm x 81mm (inc. rubber feet and connectors)
CCIR PAL System I; Ch. 21 to 69 (factory setting is 68)
+5°C to +45°C
-20°C to +60°C
320GB (160GB personal storage space)
300GB (160GB personal storage space)
IEC 60320 2-pin
female F-type 75Ω (950-2150 MHz)
female F-type 75Ω (950-2150 MHz)
RJ11, V90
DB-9 female, data communications equipment
(DCE) / EIA/TIA-232-E ITU-T V.28 115.2 kbit/s (max.)
IEC 60169-2 female
IEC 60169-2 male
IEC 60169-2 male
OPTICAL & COAXIAL digital audio sockets for 5.1 surround sound
Phono sockets (RCA)
(for future connectivity) front and rear connectors
SCART (composite video in/out; RGB in/out)
SCART (composite video out; RGB out)
1.1 type A
(for future connectivity) RJ45, IEEE802.3 10-BASE-T & 100BASE-TX
external HDD interface, SATA 1.0a
4-way mini-DIN
Pace Mk1 and Mk2 Specifications
Operating voltage:
Power consumption:
Weight:
Dimensions:
UHF modulator:
Operating temp. range:
Storage temp. range:
Hard disk capacity:
Connectors
MAINS INPUT:
DISH INPUT 1:
DISH INPUT 2:
TELEPHONE LINE:
RS-232:
AERIAL IN:
RF OUT-1:
RF OUT-2:
DIGITAL AUDIO OUT:
AUDIO OUT (L and R):
USB 2.0 :
VCR/DVD SCART:
TV SCART:
ETHERNET:
SATA:
S-VIDEO OUT:
Specifications continued
Hereby, Pace declares that this set top box is in compliance with the essential
requirements and other relevant provisions of the following Directives: 2006/95/EC
(LVD Directive); 2004/108/EC (EMC Directive); 1999/5/EC (R&TTE Directive);
2011/65/EU (Restriction on the use of certain hazardous substances in electrical
and electronic equipment - RoHS).
If you connect earthed equipment to the RS-232 port, you must use an
approved screened cable.
The model number, serial number and electrical rating of this set top box
are on a label on its base and rear.
Pace, Victoria Road, Saltaire, West Yorkshire BD18 3LF
109
