Sky HD box - Specifications

Specifications
DRX890 Specifications
Operating voltage:
Power consumption:
Weight:
Dimensions:
UHF modulator:
Operating temp. range:
Storage temp. range:
Hard disk capacity:
Connectors
MAINS INPUT:
DISH INPUT 1:
DISH INPUT 2:
TELEPHONE LINE:
RS-232:
AERIAL IN:
RF OUT-1:
RF OUT-2:
DIGITAL AUDIO OUT:
AUDIO OUT (L and R):
COMPOSITE VIDEO OUT:
USB 2.0 :
SCART:
ETHERNET:
SATA:
Specifications
230V AC; 50Hz
45W (max.) / LNB switching +13/+18VDC 275mA MAX/22kHz
4.1kg (packed)
346mm x 255mm x 73mm (inc. rubber feet and connectors)
CCIR PAL System I; Ch. 21 to 69 (factory setting is 68)
+5°C to +45°C
-20°C to +60°C
500GB (250GB personal storage space)
IEC 60320 2-pin
female F-type 75Ω (950-2150 MHz)
female F-type 75Ω (950-2150 MHz)
RJ11, V90
DB-9 female, data communications equipment
(DCE) / EIA/TIA-232-E ITU-T V.28 115.2 kbit/s (max.)
IEC 60169-2 female
IEC 60169-2 male
IEC 60169-2 male
OPTICAL & COAXIAL digital audio sockets for 5.1 surround sound
Phono sockets (RCA)
Phono sockets (RCA)
(for future connectivity) front and rear connectors
SCART (composite video out; RGB out)
1.1 type A
(for future connectivity) RJ45, IEEE802.3 10-BASE-T & 100BASE-TX
external HDD interface, SATA 1.0a
The following specifications are for the Sky±HD box made by BSkyB, Pace and Samsung. Specifications may change without notice
DRX780 Specifications
Operating voltage:
Power consumption:
Weight:
Dimensions:
UHF modulator:
Operating temp. range:
Storage temp. range:
Hard disk capacity:
Connectors
MAINS INPUT:
DISH INPUT 1:
DISH INPUT 2:
TELEPHONE LINE:
RS-232:
AERIAL IN:
RF OUT-1:
RF OUT-2:
DIGITAL AUDIO OUT:
AUDIO OUT (L and R):
USB 2.0 :
VCR/DVD SCART:
TV SCART:
ETHERNET:
S-VIDEO OUT:
230V AC; 50Hz
45W (max.) / LNB switching +13/+18VDC 275mA MAX/22kHz
5kg (packed)
399mm x 295mm x 81mm (inc. rubber feet and connectors)
CCIR PAL System I; Ch. 21 to 69 (factory setting is 68)
+5°C to +45°C
-20°C to +60°C
320GB (160GB personal storage space)
300GB (160GB personal storage space)
IEC 60320 2-pin
female F-type 75Ω (950-2150 MHz)
female F-type 75Ω (950-2150 MHz)
RJ11, V90
DB-9 female, data communications equipment
(DCE) / EIA/TIA-232-E ITU-T V.28 115.2 kbit/s (max.)
IEC 60169-2 female
IEC 60169-2 male
IEC 60169-2 male
OPTICAL & COAXIAL digital audio sockets for 5.1 surround sound
Phono sockets (RCA)
(for future connectivity) front and rear connectors
SCART (composite video in/out; RGB in/out)
SCART (composite video out; RGB out)
1.1 type A
(for future connectivity) RJ45, IEEE802.3 10-BASE-T & 100BASE-TX
4-way mini-DIN
Hereby, BSkyB declares that this set top box is in compliance with the essential requirements and other relevant provisions
of the following Directives: 2006/95/EC (LVD Directive); 2004/108/EC (EMC Directive); 1999/5/EC (R&TTE Directive);
2011/65/EU (Restriction on the use of certain hazardous substances in electrical and electronic equipment - RoHS).
If you connect earthed equipment to the RS-232 port, you must use an approved screened cable.
The model number, serial number and electrical rating of this set top box are on a label on its base and rear.
BSkyB, Grant Way, Isleworth, Middlesex TW7 5QD
108
