SECTION 6, Page 39SJKB-40-D, SJKB-40-D/F JUN. 1999
1 707753 ASSEMBLY, Door stop 1
707754 • WELDMENT, Door stop 1
103472 • WASHER, Flat 3/8” SAE 1
707749 • SPRING, Utility compression, 1/2” x 1-1/2” lg. 1
707748 • PIN, Cotter, 1/8” x 3/4” lg. 1
707751 • BUMPER, Rubber 1
2 706234 COVER PLATE 1
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 2
103996 • WASHER, Flat 5/16” SAE 2
103404 • WASHER, Lock 5/16” 2
3 707169 COVER WELDMENT, Tank side 1
706431 • EDGE TRIM AR
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. AR
103472 • WASHER, Flat 3/8” SAE AR
103999 • WASHER, Lock 3/8” AR
702862 • SCREW, Self tapping, 1/4-14 x 1” lg. 2
4 707176 COVER PLATE, Hydraulic 1
103855 • BOLT, HHCS 1/4-20 x 1/2” lg. 4
103995 • WASHER, Flat 1/4” SAE 4
104000 • WASHER, Lock 1/4” 4
5 706291 COVER, Front 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. AR
103472 • WASHER, Flat 3/8” SAE AR
103999 • WASHER, Lock 3/8” AR
6 707281 WELDMENT, Front bi-fold door 1
708528 WELDMENT, Front bi-fold door (European only) 1
103856 • HHCS 1/4-20 3/4” lg. 4
103995 • WASHER, Flat 1/4” SAE 4
104000 • WASHER, Lock 1/4” 4
103980 • NUT, Hex 1/4-20 4
707863 • • ANGLE, Bi-fold door 1
104698 • • BOLT, Machine head #10-32 x 3/4” lg. 2
701695 • • NUT, Lock #10-32 2
7 706216 WELDMENT, Engine side door 1
103855 • BOLT, HHCS 1/4-20 x 1/2” lg. 6
104000 • WASHER, Lock 1/4” 6
710188 • BUMPER, Rubber 6
8 701129 DOOR LATCH, Eingine side 2
104698 • BOLT, Machine head #10-32 x 3/4” 8
701695 • NUT, Lock #10-32 8
9 707114 WELDMENT, Cover engine, fake counterweight 1
103855 • BOLT, HHCS 1/4-20 x 1/2” lg. AR
104000 • WASHER, Lock 1/4” AR
10 704426 COUNTERWEIGHT, 3700 lbs. (4x2 Models) 1
708240 COUNTERWEIGHT, 2800 lbs. (4x4 Models) 1
700617 • PLUG, Plastic 1
708282 • BOLT, HHCS 1-8 x 3” lg. 3
107948 • WASHER, Lock 1” 3
700435 • WASHER, Flat 1” 3
11 706994 COUNTERWEIGHT 1
700617 • PLUG, Plastic 1
708282 • BOLT, HHCS 1-8 x 3” lg. 2
107948 • WASHER, Lock 1” 2
700435 • WASHER, Flat 1” 2
12 111135 PAD, Riser rest 2
103980 • NUT, Hex 1/4-20 2
103995 • WASHER, Flat 1/4” SAE 2
104000 • WASHER,Lock 1/4” 2
FIGURE 6-18. TURRET COVERS, DOORS AND COUNTERWEIGHTS
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
To Next Page
