SECTION 6, Page 49SJKB-40-D, SJKB-40-D/F JUN. 1999
FIGURE 6-25. BASE CONTROL/ELECTRICAL PANEL ASSEMBLY
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
(Ref.) PANEL ASSEMBLY, Base control -
1 704586 • ENCLOSURE, Electrical 1
2 707187 • DUCT, Wire 1” 75”
702186 • COVER, Wire duct 75”
3 707020 • DUCT, Wire 2” 38”
707188 • COVER, Wire duct 38”
4 707144 • TERMINAL BLOCK, Ground 6
5 707143 • TERMINAL BLOCK, Through 61
6 707145 • TERMINAL BLOCK, Diode 23
7 707149 • DIN RAIL, Terminal 20”
103962 • • BOLT, Macine head #10-32 x 1/2” lg. AR
104694 • • WASHER, Flat #10 AR
104185 • • WASHER, Lock #10 AR
8 707147 • END BLOCK, Terminal block 2
9 707146 • END PLATE, Terminal block 1
10 707148 • JUMPER, Terminal block 5
11 701943 • RELAY, 12 Volt sealed AR
103962 • • BOLT, Machine head #10-32 x 1/2” lg. AR
104185 • • WASHER, Lock #10 AR
104000 • • NUT, Hex #10-32 AR
12 701547 • CARD, Multi purpose controller (EDA) 1
103985 • • NUT, Hex #6-32 AR
13 701546 • CARD, Dual solenoid driver (MDSD) 1
103985 • • NUT, Hex #6-32 AR
14 102853 • SWITCH, Toggle 3 position momentary 7
15 701929 • SWITCH, Toggle 2 position momentary AR
16 (Ref.) • SWITCH ASSEMBLY, Emergency stop 1
102769 • HEAD, Emergency stop switch 1
103281 • BASE, N.C. Contact 1
17 (Ref.) • SWITCH ASSEMBLY, Key 1
102753 • HEAD, Key switch 1
104466 • • Key, #455 1
103279 • BASE, Contact 2 N.C. 1
103141 • CONTACT, N.O. 1
18 701931 • SWITCH, Ignition 1
19 706282 • GAUGE, Fuel 1
20 704732 • VOLTMETER 1
21 701925 • METER, Hour 1
22 105271 • PLUG, Recessed male 110 volt 1
113227 • • BOOT, Rubber 1
700841 • • BOLT, Machine head #6-32 x 1/2” lg. 2
103985 • • NUT, Hex #6-32 2
23 702402 • BREAKER, 15 Amp circuit 2
24 703572 • COVER, 110 Volt outlet 1
700841 • • BOLT, Machine head #6-32 x 1/2” lg. 2
103985 • • NUT, Hex #6-32 2
Parts List Continued on Page 51.
