SECTION 4, Page 4 SJKB-40-D, SJKB-40-D/FJUN. 1999
TROUBLESHOOTING (Cont.)
TROUBLE PROBABLE CAUSE REMEDY
ENGINE CRANKS BUT
WILL NOT START (Cont.)
15. Defective relay 54DCR.
16. Loose or broken wire #02 from
relay 54DCR to engine terminal
block TB4.
17. Loose or broken wire #77 from
relay 54DCR to engine terminal
block TB4.
18. Loose or broken wire #77 from
engine terminal block TB4 to
ignition coil.
19. Defective ignition coil.
20. Loose or broken wire #77 from
engine terminal block TB4 to fuel
relay 22CR.
21. Defective fuel relay 11CR.
15. Check Relay. Replace if
defective.
16. Check Continuity. Replace if
defective.
17. Check Continuity. Replace if
defective.
18. Check Continuity. Replace if
defective.
19. Refer to engine manufactures
troubling.
20. Check Continuity. Replace if
defective.
21. Check Relay. Replace if
defective.
ELECTRICAL SYSTEM (Cont.)
ENGINE CRANKS BUT
WILL NOT START FROM
PLATFORM
1. Defective platform ignition switch
S6.
2. Loose or broken wire #60 from
platform ignition switch S6 to
platform terminal block TB1.
3. Open diode D60-1 at platform
terminal block TB1.
4. Loose or broken wire #60A from
platform terminal block TB2.
5. Loose or broken wire 60A from
platform terminal block TB2 to
base terminal block TB3.
1. Check Switch. Replace if
defective.
2. Check Continuity. Replace if
defective.
3. Check Diode. Replace if
defective.
4. Check Continuity. Replace if
defective.
5. Check Continuity. Replace if
defective.
ENGINE STARTS BUT
WILL NOT KEEP RUN-
NING
1. Engine oil level low.
2. Engine overheated.
1. Check oil level. Refill to proper
level.
2. Check radiator coolant level.
Refill if low.. Check for radiator
obstruction.
CONTROLS INOPERA-
TIVE FROM PLATFORM
1. Loose or broken wire #04 from
platform terminal block TB1 to
footswitch S11.
2. Defective footswitch S11.
3. Loose or broken wire #08 from
footswitch S11 to platform
terminal block TB1.
1. Check Continuity. Replace if
defective.
2. Check Switch. Replace if
defective.
3. Check Continuity. Replace if
defective.
